Mitsubishi GX Works3 & GOT2000 From Scratch (Real Project)

Build a REAL Mitsubishi PLC + HMI Project From ZeroThis course is not theory.We will build a complete automation project from scratch using:• Mitsubishi iQ-R PLC• GX Works3• GT Designer3 (GOT2000 HMI)By the end of the course, you will have a fully structured, reusable, professional PLC/HMI template project you can use in real machines.This course is designed exactly how real automation engineers build projects in industry.What Makes This Course Different?Most PLC courses teach small disconnected examples.In this course, we build one complete machine project step-by-step:From blank project → to professional HMI + PLC architecture.You will learn how to think like an automation engineer, not just how to place instructions.What You Will BuildWe will develop a complete demo machine including:Machine Mode Control (Manual / Auto) Start / Stop / Reset logic Stacklight & Pushbutton Light reusable functionPneumatic Cylinder / Valve control with fault handlingProfessional HMI navigation & templatesScreen reuse using HMI Offset techniqueAlarm screen + scrolling alarm bannerGOT scripting for warnings & dynamic UI Reusable PLC & HMI architectureCourse Modules1. Project Setup From ScratchCreate a Mitsubishi iQ-R project the correct way:• CPU selection• Network setup• Labels & structure• Best project organization practices2. Machine Mode ControlBuild the foundation of every machine:• Manual vs Auto mode logic• Start / Stop sequence• Safety-friendly control structure• HMI mode control screen3. Professional HMI FrameworkCreate reusable HMI templates:• Header / Footer system• Reusable Menu screens• Machine Status window• Modern screen navigation design4. Reusable Stacklight & Indicator LogicCreate flexible PLC code for:• Tower lights• Pushbutton lights• ON / Slow Flash / Fast Flash modes• Reusable function structure5. Cylinder & Valve Control LogicBuild real pneumatic control:• Open / Close requests• Reed switch confirmations• Latching outputs• Fault detection & alarms6. HMI Screen Reuse Using Offsets One of the most powerful GOT features:• Build ONE screen → control MANY machines• Cylinder screens• Robot screens• Multi-station machines• Massive development time savings7. GOT Scripting & Warning PopupsMake your HMI smart:• GOT scripting basics• Dynamic warning messages• Popup banners• Smart UI behavior 8.Alarm System + Scrolling Alarm BannerBuild a professional alarm system:• Alarm history screen• Acknowledge / Delete / Reset• Scrolling alarm banner on header• Improve operator awareness 9.LabelsHow to use labels with GX Works 3 and GT Designer 3:• Create Labels in GX Works 3• Import Labels in GT Designer 3 10.Z IndexersHow to program Z Indexers in GX Works 3:• Setup Z Indexers in GX Works 3.• Offset based approach to do Block MovesWho This Course Is ForThis course is perfect for:• PLC programmers starting Mitsubishi platform• Automation engineers wanting better HMI design• Students entering industrial automation• Engineers switching to Mitsubishi iQ-R• Anyone wanting a real-world PLC/HMI template project Software UsedGX Works3GT Designer3Mitsubishi iQ-R Series PLCGOT2000 HMIAfter This Course You Will Be Able To• Start Mitsubishi projects the correct way• Build reusable PLC architecture• Design professional HMI systems• Create alarm & warning systems• Reduce engineering time using templates• Apply these skills directly in real machinesThis is the course I wish existed when I started in automation.
